The Halley E represents the most sold series of our product world-wide . In these years since the extension from 20 to 160 kVA it has almost become the synonym of Astrid .
It's a very reliable product of great flexibility. It's mostly used in the hospital and in the industrial environment.
The 125 kVA and 160 kVA versions are often used for data processing centers and crictical servers protection.
| UPS Topology |
ON-LINE DOUBLE CONVERSION |
| Output Power (CosΦ 0,8) - KVA |
20/30/40/60/80 |
| Output Power (CosΦ 1) - kW |
16/24/32/48/64 |
| Efficiency (AC ÷ AC) - %) |
>90 |
| Ambient Temperature-°C |
0 ÷ 40 |
| Audible Noise Level (according to EN 50091) |
<58 <58 < 62 db < 62 db < 62 db |
| EMC compatibility |
According to "EN50091-2" (CE label) |
| Nominal Imput Voltage - Vac |
380÷415 (Selectable) +/- 10% |
| Inverter Bridge |
IGBT with isolation trasformer |
| Nominal Output Voltage - Vac |
380÷415 (Adjustable) |
| Output Frequency (Hz) |
50 - 60 |
| Output Harmonic Distorsion With Linear Load |
<2% |
| Output Harmonic Distorsion With Non Linear Load (Crest Factor 3:1) |
<10% |
| Crest Factor (Non Linear Load) |
3:1 |
| UPS Topology |
ON-LINE DOUBLE CONVERSION |
| Output Power (CosΦ 0,8) - KVA |
100/125/160 |
| Output Power (CosΦ 1) - kW |
80/100/128 |
| Efficiency (AC ÷ AC) - %) |
>92 |
| Audible Noise Level (according to EN 50091) |
< 59 db |
| EMC compatibility |
According to "EN50091-2" (CE label) |
| Nominal Imput Voltage - Vac |
380 ÷ 415 (Selectable) +/- 10% |
| Inverter Bridge |
IGBT with isolation trasformer |
| Nominal Output Voltage - Vac |
380÷415 (Adjustable) |
| Output Frequency (Hz) |
50 - 60 (Adjustable) |
| Overload Capability |
125% for 10 min |
| Overload Capability |
200% per 100ms |
| Output Harmonic Distorsion With Linear Load |
<2% |
| Output Harmonic Distorsion With Non Linear Load (Crest Factor 3:1) |
<5% |
| Crest Factor (Non Linear Load) |
3:1 |
